CIMC Flatbed Container Dump Tipper Regrigerator Low Bed Cement Fuel Tanker Semi Trailer

Basic Info.

Model NO.	CIMC9400GHY
Independent Suspension Type	Multi-link Type
Shape	Van-type
Axle Number	3
Tire Number	12
Self-dumping	Self-dumping
ABS Anti-lock Braking System	ABS Anti-lock Braking System
Material	Iron, Aluminum, Stainless Steel
Condition	New
Prime Mover	Recommend 6X4 Type
Tyre	11r20, 12PCS
Certificate	Adr Certificate
Color	as Customers′ Request
Usage	Transporting Petrol Products
Suspension	BPW Air Suspension
Langing Gear	Fuwa or Jost Dual-Speed Landing Gear
Kingpin	Jost 2" or 3.5"
Axle Brand	Fuwa or BPW Axle
Tank Barrel	Aluminum Alloy Xtral728 Material
Transport Package	Nude Packing
Specification	ISO/TS16949, DOT, CCC, ISO, SGS
Trademark	CIMC
Origin	Jiangsu, China
HS Code	87163910
Production Capacity	1000PCS/Month

Product Description

All CIMC vehicles are customizable, welcome inquiry!!!

Specs of CIMC 3 Axle Fuel Tanker Trailer 40CBM 4 Compartment
Dimension: 12950x2500x3950(mm)King pin setting: 1350(mm)Kin pin plate height: 1310(mm)Axle Space:6650mm+1310mm+1310mmTare weight: 9500kgLoading capacity: 45000LConfigration:Lanidng Gear: Two speed manual operation type with sand shoeKing pin: 2" bolted typeBrake system:Dual line pneumatic brake system.ABS:NoBrake Chamber: Type 30/30 spring brake system on all axlesSuspension: spring suspensionAxle:FUWA axle, 13 ton capacity/set,3pcsTire:11.00R20, 12 pcsRim:8.0-20 12 pcsTool box:1pcsSpare Tire Carrier: 2 unitsTANK SPECSCompartment: 4 compartment, 10KL-10KL-10KL-10KLTank Material:Carbon steel, thickness 5mmBulkhead:Thickness is 5mmBaffle:Thickness is 4mm approxShape of Tank:Ellipse (double "d")Test pressure designed:36kpaManhole: 4 units , 20"Aluminum alloyFoot valves: 4 units ,4"Aluminum alloyDischarge ball valve: 4 units, 2.5"Aluminum alloyRuler: 1pcs each compartment, calibratedStainless steel pneumatic handrailDrainage tube: front and rear Water tank for tires: Equipped
OTHERSFire extinguisher: 2pcsManhole: oneDischarge hose:4x6mmHose carries:2pcs

Specs of CIMC 40FT THREE AXLE FLAT BED TRAILER 50T
PARAMETER	Dimension	L*W*H: 12404X2480X H(mm)
	Axle space	6790mm+1310mm+1310mm
	Payload	50000kg
OEM	Landing gear	TSU 28ton
	Kingpin	2"(50#) bolted type, JOST
	Brake system	Dual line pneumatic brake system. WABCO valve
	Brake chamber	Type 30/30 brake chamber on three axle
	Suspension	Spring suspension
	Leaf Spring	7pcs
	ABS	No
	Axle	FUWA axle, 13 ton capacity/set,3pcs
	Tire	11R22.5-16PR, 13pcs, Linglong Brand
	Rim	8.25-22.5 , 13pcs, made in china
	Twist locks	8pcs
	Tool box	1 pcs
	Spare tire carrier	1pcs
OTHERS	Floor	3mm checked plate
	Trailer rear end	Cut off
	Painting	As customer request

Specification of CIMC 3 Axle 69.5cbm Cement Tanker Trailer :
Type: Air Discharge Tanker For Carrying Cement
DIMENSION:
Overall Length : 13,860 mm
Overall Width : 2,500 mm
Overall Height : 4,050 mm
Wheelspan : 8400mm
Axle Spacing : 1,310 mm
TANK:
Tank Volume : 69.5cbm
Pipe material : Carbon steel
Discharging Hose Diameter : 4"
Discharging valve 4" butterfly valve
Discharging Hose Length : 7,000 mm
Hose quick coupling : 4" female quick coupling.
Fluidizer : Aeration pad with air bag.
Discharging capacity : 1m3/min
Working pressure : 0.2 Mpa
Test pressure : 0.3 Mpa
Manhole : Three.
MAX. Horizontal Discharging Distance: 5,000 mm
MAX. Vertical Discharging Distance : 15,000 mm
RUNNING GEAR:
Suspension : Undermount tri-axle suspension with equalizer;
9pcs Leaf Spring.
Axle : FUWA Square axle,16T capacity,3 pcs.
Brake : Dual line pneumatic brake system. Without ABS.
Parking Brake : Type 30/30 spring brake system on two axles
Wheel : 9.0-20 ,10 holes steel Disc wheel, 13pcs, made in china.
Tire : 12R20 18PR, 12pcs , Brand Linglong
King Pin : 3.5"(90#) bolted type, JOST.
LANDING LEG: TSU 28ton
PNEUMATIC SYSTEM:
Electromotor : WEICHAI HUAFENG ZHBP1 , Made in China
Air Compressor : 12m3/min Made in China
Mounted at the front of trailer,
ELECTRICAL:
Voltage : 24 Volt.
Receptacle : 7 way
Light: Front Marker Lamp : White
Side Marker Lamp : Amber
Rear Lamp : Red
Turn Signal Lamp : Amber
STRUCTURAL WEIGHT RATING:
Tare Weight : 12,200 Kg.
Pay Load :83,400 Kg.
G.V.W.R. : 95,600 Kg.
PAINTING:
The tanker's color is as per your requirement.
The side guard is red and white.
Note:all the details not mentioned above should comply with Chinese regulations.
More photos for your reference:
